Watch Band Pin 1.80mm Nickel Plated Quick Release Pegged Spring Bar

Watch Band Pin 1.80mm Nickel Plated Quick Release Pegged Spring Bar

SKU:
Watch Band Pin 1.80mm Nickel Plated Quick Release Pegged Spring Bar
$1.50
Bulk Pricing:

Below are the available bulk discount rates for each individual item when you purchase a certain amount

  • Buy 10 - 49 and get 5% off
  • Buy 50 - 99 and get 10% off
  • Buy 100 or above and get 15% off
Current Stock:
Description

These are the 1.80mm pegged and nickel plated spring bars. Each size spring bar is sold individually, allowing you to decide the size of the replacement spring bar you need. Simply select the size you need from the drop down menu above.

  • Sold individually
  • Nickel plated spring bars
  • Pegged
  • 1.80mm diameter
  • Come in 8 different lengths: 14mm, 16mm, 18mm, 20mm, 21mm, 22mm, 23mm and 24mm
  • Note: Sizes are determined by the compressed length of the spring bar. Sizes are approximate as measurements may vary slightly by gauge.



    Part Number Fits Lug Width Compressed Length Overall Length Body Length Overall Height of Bar to Peg Peg Diameter Tip Diameter
    82.5148 14mm 13.8mm 16.5mm 13.8mm 3.8mm 1.5mm .90mm
    82.5168 16mm 15.7mm 18.3mm 15.7mm 3.7mm 1.5mm .90mm
    82.5178 17mm 16.8mm 19.2mm 16.8mm 3.8mm 1.5mm .90mm
    82.5188 18mm 17.8mm 20.0mm 17.8mm 3.7mm 1.5mm .80mm
    82.5198 19mm 18.7mm 21.1mm 18.7mm 3.8mm 1.5mm .90mm
    82.5208 20mm 19.7mm 22.1mm 19.7mm 3.8mm 1.5mm .90mm
    82.5218 21mm 20.7mm 23.1mm 20.7mm 4.0mm 1.5mm .90mm
    82.5228 22mm 21.7mm 24.3mm 21.7mm 4.3mm 1.5mm .90mm
    82.5238 23mm 22.7mm 25.1mm 22.7mm 3.8mm 1.5mm .90mm
    82.5248 24mm 23.8mm 26.3mm 23.8mm 3.8mm 1.5mm .90mm
